10kA Surge Protection Device SPD-10S-277S

Description :

SPD-10S-277S thermally protected Surge Protective Device is a self-protected device which is specially designed to be used in outdoor and commercial LED lighting fixtures for transient overvoltage protection. It is constructed with thermally protected varistor technology. Its built-in thermal disconnect function provides additional protection to prevent catastrophic failure and fire hazard even under the extreme circumstances of varistor end-of-life or sustaining over voltage conditions. It also features a built-in LED indicator that notifies when replacement of the module is needed

Features :

  1. Series connection style
  2. UL1449 type 4 component assemblies
  3. Line to Ground & Line to Line protected
  4. 10kA maximum discharge current(Imax), 8/20us
  5. Thermally protected
  6. Double insulation cable wire
  7. LED status indicator
  8. IP66 design for indoor or outdoor installations
  9. 10KV surge protection capability

Applications :

  1. Outdoor and commercial LED Lighting
  2. Roadway lighting
  3. Traffic lighting
  4. Digital signage
  5. Wall wash lighting
  6. Parking garage/lot lighting
  7. Flood lighting
  8. Tunnel lighting
  9. Street lighting
