M/HSD24.1 KNX Ceiling Mount OmniSense Sensor

Overview :

  • KNX Ceiling Mount OmniSense Sensor can detect movement at a distance of up to 24 meters, which can be controlled logically by different input conditions. Meanwhile, the parameters can be set via ETS software to select the detection area, and 6 detection areas in total can be selected.
  • OmniSense Sensor แบบติดตั้งบนเพดาน KNX สามารถตรวจจับการเคลื่อนไหวได้ไกลถึง 24 เมตร ซึ่งสามารถควบคุมได้อย่างมีเหตุผลตามเงื่อนไขอินพุตต่างๆ ในขณะเดียวกัน พารามิเตอร์สามารถตั้งค่าได้ผ่านซอฟต์แวร์ ETS เพื่อเลือกพื้นที่การตรวจจับ และสามารถเลือกพื้นที่การตรวจจับได้ทั้งหมด 6 พื้นที่



หมายเหตุ : สินค้ารายการนี้ มีศูนย์ บริการในประเทศ มีบริการติดตั้ง สอนการใช้งานฟรี และให้คำแนะนำกรณีมีช่างติดตั้งเอง จัดส่งถึงมือลูกค้าก่อนชำระเงิน ค่าจัดส่งค่าใช้จ่ายอัตตราของผู้ให้บริการรายต่างๆ ตามบิล สำหรับร้านค้าและช่างมีราคา พิเศษ ร้านค้าหรือช่างสามารถสมัครสมาชิกสะสมแต้ม เพื่อแลกของรางวัลได้ที่หน้าเวปไซด์ มีของรางวัลหลายรายการ ( สินค้านี้ซื้อ 1ชิ้น ขึ้นไป ส่งฟรี ) รับตัวแทนจำหน่าย ฟรีข้อมูลสินค้า รับสอนประกอบและตรวจซ่อมฟรี / ไม่มีค่าใช้จ่าย / มีอะไหล่และเครื่องมือในราคาช่าง / มีบริการปรับปรุง อาคาร, เครื่องจักรเพื่อให้มีประสิทธิภาพในการประหยัดพลังงาน ให้ระบบทำงานเพื่อเพิ่มประสิทธิภาพลดการซ่อมยึดอายุการใช้งาน สินค้านี้ขายยกลังในราคาส่ง ราคาที่เสนอต่อ ชิ้น สินค้านี้ต้องตรวจสอบล่าสุดก่อนส่งถึงมือผู้ใช้งานตามมาตรฐานของผู้ผลิตเพื่อลดปัญหาการเสื่อมคุณภาพจากการจัดเก็บที่ไม่ถูกต้องเป็นเวลานาน

KNX Ceiling-Mount OmniSense Sensor

Feature

  • With 2CH lighting control, 4 sections of brightness and delay time can be set in dimming output. With gradually dimming effect, the sensor supports automatic or semiautomatic mode. Telegram locking/unlocking and delay time can be set.
  • With 2CH constant brightness control, 4 dimming values and forced operation can be set.
  • The sensor has 5 logic blocks and each block can control 10 object outputs. Dry contact and telegram locking/ unlocking and delay time can be set.
  • Control types: Switch control, Absolute dimming control, Curtain control, Alarm control, Percentage control , Sequence control, Scene control, String(14 bytes) control, Threshold control, Logic combination control.
  • Logic inputs: PIR sensor status, brightness value, temperature value, dry contact status and external telegrams.
  • 2 logical relations: AND, OR.
  • 2 working modes: Single mode and master / slave mode.
  • 2CH dry contact can be set as dry contact and LED status display and the operation function can be set as switch control, dimming control, scene control.
  • The detection area can be selected.

KNX Ceiling-Mount OminSense Sensor Parameters

 Basic Parameters

 External Environment

Specifications

  • Working voltage 21~30V DC
  • Working current 10mA/30V DC
  • Communication KNX
  • Cable diameter of KNX terminal 0.6 - 0.8mm
  • PIR detection range Φ30m (Installation height: 3m)
  • Working temperature -5℃~45℃
  • Working relative humidity ≤90%
  • Storage temperature -20℃~60℃
  • Storage relative humidity ≤93%

  • Dimensions Φ84×42 (mm)
  • Net weight 60g
  • Housing material ABS, PC
  • Installation
  • Ceiling mount
  • Protection rating (Compliant with EN 60529) IP20
